Piezo Ceramic Drive Drop-on-Demand.
Light weight and compact. User considerate design.
Light, compact body for simple, easy operation.
Easily attached to a production line.
Can be easily operated by anyone.
Includes a variety of functions despite its low price.
Can print numberings, automatic calendars, and expiration dates.
Backup your data by connecting to a computer.
Copy data between devices with communication cables.
Features our in-house developed print head.
By using our own print head and ink, we also offer reliable after-sales service.
Download
| Printing system | Piezo ceramics drive on demand. |
|---|---|
| Maximum supported line speed | 200m / min (concentration 1) ～ 31m / min (concentration of 9) |
| Nozzle arrangement | 32 nozzles, 2 holes / nozzle |
| Ink ejection direction | Horizontal |
| Character height | 2～20mm, 25.4mm（when vertical） |
| Number of heads | 1 |
| Ink type | Black: CK RED: CK |
| Work detection | Phototube (head fixing type external type) |
| Number of printintable stages | 1 stages (32×32dot), 2 steges (16×16dot) |
| Number of recorded messages | 30messages |
| Number of recorded characters per message. | 48characters |
| Character type | Alphabet (upper case / lower case), numbers, symbols, Japanese hiragana, katakana, kanji(48characters), User recorded characters (customer recorded 180 characters selected arbitrarily, before shipment). |
| Character font | Gothic font (16 dot font bold, fine print selectable). |
| Date Time (expiry date) Printing function | Year (Western / Japanese calendar), month, day, hour (12/24, minute), free format, offset value can be set, calendar character allocation function. |
| Numbering function | Max.of 8 digits, (up/down), repeat, increment value setting, zero suppression |
| Bar code printing function | Improper |
| Figure | Improper |
| External interface | I / O: 3 points (preparation ready / low ink / alarming) RS-232C: data backup and restoration, only usable for software version up |
| Use environment (temperature, humidity) | 5-35°C, 10-80% (however, non-condensing) |
| Power supply | Less than AC100V |
| Ground | D type grounding |
